Detect and correct belt misalignment before damage occurs.
Continuous Belt Deviation Monitoring
Continuous Belt Deviation Monitoring
Constantly tracks belt alignment to detect deviation in real time.
Automatic Deviation Recognition & Correction
Automatic Deviation Recognition & Correction
Intelligently identifies belt deviation and initiates corrective actions automatically.
High-Accuracy Deviation Measurement
High-Accuracy Deviation Measurement
Delivers precise deviation measurements for reliable alignment control.
Trend Analysis & Data Storage
Trend Analysis & Data Storage
Stores historical deviation data to analyse trends and long-term performance.
Severe Deviation Alarm Triggering
Severe Deviation Alarm Triggering
Activates alarms immediately when deviation exceeds critical thresholds.
Adaptive Correction Control
Adaptive Correction Control
Automatically adjusts correction parameters to changing operating conditions.
How the System Works
Deviation sensors continuously track the conveyor belt’s position during operation to ensure accurate alignment at all times.
The system compares belt movement against predefined deviation thresholds to determine when misalignment exceeds acceptable limits.
When excessive deviation is detected, the system automatically initiates corrective action to restore proper belt alignment and maintain stable operation.
Operating & Environmental Specifications
- Applicable belt speed: 0 – 8 m/s
- Applicable belt width: 650 – 2400 mm
- Deviation accuracy: ≤ 5 mm
- Working temperature: −30 °C to +60 °C
- Relative humidity: ≤ 95% RH
- Power supply: 85 – 264 VAC
- Continuous operation: 7 × 24 h
Integrates seamlessly with monitoring sensors
Each sensor is installed at a specific point along the conveyor line, creating a complete, end-to-end monitoring system.
Click on any sensor location to explore how it works and what it monitors.
